Mackenzie, J. A.; Hill, N. A.

Background and Objective: Lung cancer is one of the most frequently diagnosed cancers worldwide. While non-surgical treatment options have increased in number and efficacy, lung resection for primary cancers is still a mainstay of treatment. Lung resection has been shown to impair right ventricular function, although the mechanism for the impairment remains unclear. Wave intensity is increasingly used as a metric for increased post-operative afterload. Here, we develop a computational framework to assess the impact of simulated lung resection on wave intensity to establish that post-operative changes in wave intensity are attributable to the change in pulmonary artery morphometry. Methods: We analyse a 48 pulmonary arterial surfaces segmented from CT images in patients with no evidence of lung disease to obtain 1D representations of the pulmonary vasculature. For each pulmonary vasculature we sequentially remove vessel branches to mimic post-operative morphometric changes to the arterial network. Using an established 1D computational flow model, we simulate pulsate blood flow in 44 pre-operative cases and 1596 post-operative cases. We compute wave intensity in the main, right, and left pulmonary arteries for all simulations. Results: We compare the change in computed wave intensities pre- versus post-operatively to the results of an experimental clinical study comparing pre- and post-operative wave intensity in a 27 patient cohort. We see good agreement between the changes in the parameters of wave intensity between this study and those reported in the clinical study. Further, we capture flow distribution the changes pre- versus post-operatively which indicates that the computational model behaves as expected. Conclusions: In this preliminary study on a computational framework to capture changes in pulmonary arterial haemodynamics following lung resection, we have shown that our model and analysis pipeline is capable of capturing post-operative changes to wave intensity and flow redistribution between the pulmonary arteries following lung resection. These results motivate further research to develop and validate a patient specific model which is an area of active research for us.
