Chishty, H. A.; Lee, Z. D.; Balaga, U. K.; Sergi, F.

Wearable devices for gravity balancing have high potential for impact across domains, including neuromotor rehabilitation and occupational systems. Devices made from compliant mechanisms, optimized to achieve specific compensation moments at target joints, have proven effective, but thus far have solely been optimized towards gravity compensation and not other wearability criteria. In this work, we propose a multi-objective optimization framework, based on particle swarm optimization, to design a soft, gravity balancing shoulder orthosis, while taking into account wearability constraints such as undesired loading directions and device size. Using this custom framework, we pursued multiple stages of orthosis design and optimization, selecting multiple solutions to be translated to real-world prototypes. These solutions were realized via 3D printing with thermoplastic polyurethane and evaluated for mechanical performance on benchtop and in-vivo. In-vivo testing on 6 healthy individuals demonstrated relative reductions in muscle activity for the anterior deltoid and upper trapezius, by 53 % and 71 % respectively when operating the orthosis for static tasks within functional shoulder ranges of motion. Changes in muscle activation were also were observed across other muscles, including the posterior deltoid, as well as in dynamic tasks at different speeds.
