Cai, C.; Flake, C.; Nameny, A.; Hudson, N. E.; Bannish, B. E.; Guthold, M.

Background. Scanning electron microscopy (SEM) is widely used to determine fibrin fiber structural properties such as fiber diameter and fiber length. However, conventional SEM preparation protocols are time-consuming and typically require conductive sputter coating. The coating process introduces an additional layer onto the sample surface and may influence measurements of nanoscale fiber structure. Furthermore, preparation of purified fibrinogen clots often follows protocols originally developed for plasma clots, resulting in unnecessary processing steps. Objective. To evaluate indium tin oxide (ITO) as a flat, conductive substrate for SEM imaging of fibrin fibers, investigate the effects of sputter coating on measured fiber diameter, and develop a simplified SEM preparation protocol for purified fibrinogen clots. Methods. Platelet-poor plasma clots and purified fibrinogen clots were formed on ITO substrates and imaged by SEM following 0 s, 45 s, or 90 s sputter coating. Fibrin fiber diameters were quantified and compared across coating conditions. For purified fibrinogen clots, an ITO-based simplified preparation protocol, in which clots were formed and imaged directly on the conductive ITO surface, was compared with a previously developed, standardized SEM protocol, in which clots were formed in microtube lids and subsequently transferred onto carbon tape for imaging. Results. Fiber diameter measurements were affected by sputter coating duration, with increasing coating time resulting in larger apparent fiber diameters. Plasma and purified fibrinogen clots exhibited distinct fiber diameter distributions and coating responses. For purified fibrinogen clots, the simplified ITO-based protocol produced fiber diameter measurements that were not significantly different from those obtained using the standardized lid-to-carbon-tape workflow when identical coating times were applied. Conclusions. ITO provides a practical conductive substrate for SEM imaging of fibrin fibers and enables substantial simplification of purified fibrinogen clot preparation. When coating conditions are matched, the simplified ITO-based protocol yields fiber diameter measurements comparable to those obtained using the previously standardized lid-to-carbon-tape workflow. These findings support the use of ITO as an alternative conductive imaging substrate and provide a simplified workflow for SEM analysis of purified fibrinogen clots. By reducing washing and transfer steps, this workflow may also provide a useful platform for future controlled studies of fibrin interactions with added proteins or other associated components.
