Zihan Zhao, Baotong Lu, Shengjie Lin, Yizou Chen, Jing Liu, Yanqi Zhang, Ziming Miao, Ming-Chang Yang, Haiying Shen, Qi Chen, Fan Yang

Long-context LLM serving is bottlenecked by the cost of attending over ever-growing KV caches. Dynamic sparse attention promises relief by accessing only a small, query-dependent subset of the KV state per decoding step and extending the KV storage to CPU memory. In practice, however, these algorithmic savings rarely translate into end-to-end system-level gains because sparse methods typically operate at different granularities and thus rely on ad hoc, per-algorithm implementations. At the same time, hierarchical KV storage introduces a new systems bottleneck: retrieving fine-grained, irregular KV subsets across the GPU-CPU boundary can easily erase the benefits of sparsity. We present SPIN, a sparse-attention-aware inference framework that co-designs the execution pipeline with hierarchical KV storage through three techniques: (1) a unified partition abstraction that maps different sparsity granularities onto a shared page-based KV substrate; (2) a locality-aware KV cache manager that dynamically sizes per-request HBM budgets and uses a GPU-friendly bucketed LRU policy to cut PCIe round-trips; and (3) a two-level hierarchical metadata layout sized to the active working set rather than the worst-case address space. Built on vLLM with three representative sparse attention algorithms, SPIN delivers 1.66-5.66x higher end-to-end throughput and 7-9x lower TTFT than vLLM, and reduces TPOT by up to 58% over the original sparse-attention implementations.
